Page 80: Test patterns
NioWatch operation
System manual E1
81
3. Click the OK button.
The calibration and the luminance will be reset to the latest
calibrated position.
Note:
When you start up the system, the calibration is also reset to
the latest calibrated position. The luminance, however, is
kept at the latest value.
To view a graph showing the result of the latest calibration:
1. In the Calibration tab dialog, click on Show calibration
chart.
This button is available only if the display has been
calibrated with a sensor before.
2. A graph is shown displaying the latest calibration compared
to the theoretical display function.
To revert to the default factory settings:
1. In the Calibration tab dialog, click on Reset.
2. As a result, the settings are restored to the default factory
values.
Test patterns
Test Patterns
Figure 42: Test Patterns dialog
