11
Connecting the RS27/RS28 Foot Switc
h
................................................................................................................................................................
Note
The RS27/RS28 foot switch works only with the DSS Player.
Connecting the RS27/RS28 Foot Switch
Connecting to a Serial Port
1 Connect the foot switch cable to
the serial adapter cable.
2 Connect the serial adapter cable to
the PC’s serial port.
Foot switch setting
3 Start the DSS Player and select
“Foot Switch Settings” from the
“Tools” menu.
4 Select the foot switch connection
method and the function for each
of the three switches.
1 2
1 2
USB adapter
Serial adapter
Windows Macintosh
Connecting to a USB Port
1 Connect the foot switch cable to
the USB adapter cable.
2 Connect the USB adapter cable to
the PC’s USB port.
Windows
