*QuickSteamer PowerBrush models only
Turn the machine off and unplug from wall outlet.
Remove clean and dirty water tanks.
Lie machine down to access the bottom of the machine.
Unscrew the brush cover.
Remove the brush end cap and remove belt from brush.
Brush can now be removed.
Belt can be removed by sliding off the motor pulley.
Clean or replace belt. Attach belt to motor pulley and
brush, insert brush into right side end cap.
Reattach the left end cap.
Slide brush with the end cap attached back into place.
Replace the brush cover and screw into place.
Belt and Brush Removal - 2070 Series only
10.
11.
10.
11.
3. 4.
5. 5A.
6.
7.
9. 8.
1.
2.
3.
4.
5.
6.
7.
9.
8.
