SHDSL VPN Firewall Bridge/Router
Chapter 4: Configuration
RFC 1483 Bridged Connections
Description: User-definable name for the connection.
VPI and VCI: Enter the information provided by your ISP.
ATM Class: The Quality of Service for ATM layer.
Encapsulation method: Select the encapsulation format, this is provided by your ISP.
Acceptable Frame Type: Specify what kind of traffic can through this connection, all traffic or only VLAN
tagged.
Filter Type: Specify the type of ethernet filtering performed by the named bridge interface.
All Allows all types of ethernet packets through the port.
Ip Allows only IP/ARP types of ethernet packets through the port.
Pppoe Allows only PPPoE types of ethernet packets through the port.
PVID for Untagged Frames: PVID is known as Port VLAN Identifier. When an untagged packet is
received by input port(s), this packet will be tagged with specified PVID. The valid value range for PVID is
1~4094.
39
