Billy Goat PR550 - Manual (Page 11)

Part No. 350324 Form No. F031605A Page 11 of 16
PARTS DRAWING
POWER RAKE SEEDER BOX KIT
P/N 350325
PART S LIST
ITEM NO. PA RT NO. DE SCRIPTION QTY
1 350321 BOX PLASTIC DROP SEE DER M AIN BODY 1
2 350306 BRACKET ADJ DROP S EEDER AS SY 1
3 350276 BA R DOOR LINKGA GE 1
4 350320 SHAFT PLAS TIC DROOP S EEDER 1
5 350271 PLATE DOOR DROP SEE DER 1
6 350272 PLATE DOOR DROP SEE DER E ND 1
7 350273 PLATE DOOR DROP SEE DER A RM 1
8 350322 BOX PLASTIC DROP SEE DER LID AS SE MB LY 1
9 350319 SP ROCKET 16T #43 0.625 B ORE 1
10 8171003 W AS HER 5/16 FLA T CUT 1
11 900321 BE ARING CLIP 1.375 OD 4
12 350335 GUA RD SP ROCK ET 1
13 400217 SP RING TENSION 2
14 8024040 BOLT CARRAIGE 5/16 - 18 X 1 1
15 8024021 BOLT CARRIA GE 1/4-20 X 3/4" 1
16 350286 SCRE W SHE ET ME TAL 4
17 8160001 NUT LOCK 1/4 1
18 350332 BRACKET SLOT PLASTIC S EEDER BOX 1
19 8160002 NUT LOCK 5/16 1
21 350318 SP ROCKET W HEE L 16T 1
22 350280 W AS HER 0.906 OD X 0.656 ID 4
24 350329 CHAIN 35 P ITCH 1
25 8197031 PIN COTTER 1/8" X 1" 1
26 350331 ROLL P IN 1/8 - 1 3/4 1
28 8172007 W AS HER 1/4 S AE 1
29 8154007 NUT HEX 10-24 2
30 8059136 SCRE W CAP #10-24 X 3/4 2
PART S BAG SEEDER BOX KIT
15 8024021 BOLT CARRIA GE 1/4-20 X 3/4" 2
17 8160001 NUT LOCK 1/4 2
19 8160002 NUT LOCK 5/16 (REQUIRE ON THE OLD MODELS ONLY ) 4
20 8177011 W AS HER LOCK 5/16 4
23 8041026 SCRE W CAP 5/16-18 x 3/4 4
27 8172020 W AS HER 5/16 FE NDE R 4
28 8172007 W AS HER 1/4 S AE 2
31 8171006 W AS HER 1/2 FC 3
32 8161044 NUT LOCK 1/2" THIN HGT 1
- 350327 LIT SEE DER B OX (INCLUDE S TE MP LATE) 1
