If you use a protection box (the additional acces-
sory), the protective floor directly below the appli-
ance is not necessary.
PRODUCT DESCRIPTION
General overview
145 mm
145 mm
120/175/2
10 mm
170 mm
265 mm
1 2
4
3 5
1 Single cooking zone 1200 W
2 Oval zone 1500/2400 W
3 Single cooking zone 1200 W
4 Control panel
5 Triple cooking zone 800/1600/2300 W
Control panel layout
5 1 2 3 4
11 9 10 8 7 12 6
Use the sensor fields to operate the appliance. The displays, indicators and sounds tell which
functions operate.
sensor field function
1 It activates and deactivates the appliance.
2 It locks/unlocks the control panel.
3 Cooking zones' indicators of timer It shows for which zone you set the time.
4 The timer display It shows the time in minutes.
