ARRI ULTRA 16 - Manual (Page 10)

10
Name Type Aperture Close focus (1) Length Front diameter Weight Horiz. angle of view
(lens mount to front) Super 16 (2)
Ultra 16 T1.3 / 6 mm Distagon T* XP T1.3 to T16 0.20 m / 8“ 91.6 mm / 3.6“ 95 mm / 3.7“ 1.0 kg / 2.2 lbs 90.22°
Ultra 16 T1.3 / 8 mm Distagon T* XP T1.3 to T16 0.30 m / 12“ 91.6 mm / 3.6“ 95 mm / 3.7“ 1.0 kg / 2.2 lbs 75.83°
Ultra 16 T1.3 / 9.5 mm Distagon T* XP T1.3 to T16 0.30 m / 12“ 91.6 mm / 3.6“ 95 mm / 3.7“ 1.0 kg / 2.2 lbs 66.34°
Ultra 16 T1.3 / 12 mm Distagon T* XP T1.3 to T16 0.30 m / 12“ 91.6 mm / 3.6“ 95 mm / 3.7“ 1.0 kg / 2.2 lbs 55.32°
Ultra 16 T1.3 / 14 mm Distagon T* XP T1.3 to T16 0.30 m / 12“ 91.6 mm / 3.6“ 95 mm / 3.7“ 1.0 kg / 2.2 lbs 48.17°
Ultra 16 T1.3 / 18 mm Distagon T* XP T1.3 to T16 0.30 m / 12“ 91.6 mm / 3.6“ 95 mm / 3.7“ 1.2 kg / 2.6 lbs 37.88°
Ultra 16 T1.3 / 25 mm Distagon T* XP T1.3 to T16 0.30 m / 12“ 91.6 mm / 3.6“ 95 mm / 3.7“ 1.2 kg / 2.6 lbs 27.82°
Ultra 16 T1.3 / 35 mm Planar T* XP T1.3 to T16 0.35 m / 14“ 91.6 mm / 3.6“ 95 mm / 3.7“ 1.1 kg / 2.4 lbs 20.46°
Ultra 16 T1.3 / 50 mm Planar T* XP T1.3 to T16 0.40 m / 16“ 91.6 mm / 3.6“ 95 mm / 3.7“ 1.2 kg / 2.6 lbs 14.76°
Technical Data
(1) Close focus is measured from the film plane.
(2) Horizontal angle of view for a Super 16 camera aperture
(DIN 15602 and ISO-5768-1998, aspect ratio 1:1.66, dimensions 12.35 mm x 7.5 mm / 0.486" x 0.295").
T* XP is the trademark for the improved Zeiss anti-reflex lens coating that reduces
veiling glare and other reflections. XP stands for extended performance.
All data subject to change without notice.
Ident. Numbers
Ultra 16 T1.3 / 6 mm with meter focus scale K2.47560.0
Ultra 16 T1.3 / 8 mm with meter focus scale K2.47561.0
Ultra 16 T1.3 / 9.5 mm with meter focus scale K2.47562.0
Ultra 16 T1.3 / 12 mm with meter focus scale K2.47563.0
Ultra 16 T1.3 / 14 mm with meter focus scale K2.47564.0
Ultra 16 T1.3 / 18 mm with meter focus scale K2.47580.0
Ultra 16 T1.3 / 25 mm with meter focus scale K2.47581.0
Ultra 16 T1.3 / 35 mm with meter focus scale K2.47582.0
Ultra 16 T1.3 / 50 mm with meter focus scale K2.47583.0
Ultra 16 T1.3 / 6 mm with feet focus scale K2.47565.0
Ultra 16 T1.3 / 8 mm with feet focus scale K2.47566.0
Ultra 16 T1.3 / 9.5 mm with feet focus scale K2.47567.0
Ultra 16 T1.3 / 12 mm with feet focus scale K2.47568.0
Ultra 16 T1.3 / 14 mm with feet focus scale K2.47569.0
Ultra 16 T1.3 / 18 mm with feet focus scale K2.47584.0
Ultra 16 T1.3 / 25 mm with feet focus scale K2.47585.0
Ultra 16 T1.3 / 35 mm with feet focus scale K2.47586.0
Ultra 16 T1.3 / 50 mm with feet focus scale K2.47587.0
