If you use a protection box (the additional acces-
sory), the protective floor directly below the appli-
ance is not necessary.
PRODUCT DESCRIPTION
General overview
120/180
mm
145
mm 145/210/270
mm
265
mm
170
mm
1 2
4 3 5
1 Single cooking zone 1200 W
2 Triple cooking zone 1050/1950/2700 W
3 Oval zone 1400/2200 W
4 Control panel
5 Double cooking zone 700/1700 W
Control panel layout
12 8 9 10 7 11 6 13 5
3 4 1 2
Use the sensor fields to operate the appliance. The displays, indicators and sounds tell which
functions operate.
sensor field function
1 It activates and deactivates the appliance.
2 It locks/unlocks the control panel.
3 Cooking zones' indicators of timer It shows for which zone you set the time.
