14
Technical Data
Article number 97212
operating voltage 12 v
power output (max.) 70 w
current (max.) 5 A
UsB connection 5 v / 1 A
Fuse 5 A
weight 108 g
Dimensions
(not including cable)
9 x 6 x 4 cm
AssEMBlY AnD connEctIon
Connection to the 12 V vehicle socket in the vehicle:
1. Insert the vehicle plug [4] into the 12 v vehicle socket in the vehicle.
2. position the double plug socket so that neither the device nor the cable is in
your way while driving.
opERAtIon
As soon as the vehicle plug [4] is inserted into the 12 v vehicle socket and
there is a power supply, the lED turns red. the double plug socket is now
working and devices can be connected to both 12 v vehicle sockets and to the
UsB connection socket.
