AEG Voxtel D570 - Manual (Page 19)

19
UK
11.2 After the Guarantee has expired
If the unit is no longer under Guarantee, contact us via www.
aegtelephones.eu
This product works with rechargeable batteries only. If you put
nonrechargeable batteries in the handset and place it on the base, the
handset will be damaged and this in NOT covered under the warranty
conditions.
12 TECHNICAL DETAILS
Standard DECT
Frequency range 1.88 to 1.9 GHz (bandwidth = 20 MHz)
Channel bandwidth 1.728 MHz
Operating range Up to 300m outdoors; Up to 50m indoors
Operating time Standby: 200 hours, Talking: 16 hours
Battery charge time: 15 hours
Temperature range Operating 0° C to 40° C,
Storage -20° C to 60° C
Electrical power
tVT04EEU06045 / VT04EUK06045
input 100-240VAC 50/60Hz 150mA,
output 6VDC 450mA
tS003IB0600045/S003IV0600045
input 100-240VAC 50/60Hz 150mA,
output 6VDC 450mA
Battery Information
Type Ni-MH (Rechargeable battery)
Voltage Rating 800mAh, 2 X 1.2V AAA Size
Port specification
The port (connected to the mains power supply) is a SELV port with
respect to EN41003.
The port (connected to the telephone line) is a TNV port with respect to
EN41003.
