If you use a protection box (the additional acces-
sory), the protective floor directly below the appli-
ance is not necessary.
PRODUCT DESCRIPTION
General overview
145
mm
145
mm
120/180
mm
120/175/210
mm
3
5
1 2
4
1 Single cooking zone 1200 W
2 Double cooking zone 700/1700 W
3 Single cooking zone 1200 W
4 Control panel
5 Triple cooking zone 800/1600/2300 W
Control panel layout
1 2 7 3 4 5 6
8 9 10 11
Use the sensor fields to operate the appliance. The displays indicators and sounds tell which
functions operate.
sensor field function
1 It activates and deactivates the appliance.
2 It locks/unlocks the control panel.
3 A heat setting display It shows the heat setting.
4 Cooking zones' indicators of timer It shows for which cooking zone you set the time.
