AEG BS 18C LI - Manual (Page 8)

14 15
BS 18 C
......................0-450 min -1
....................0-1650 min -1
...........................52 Nm
...........................18 V
..........................1/2 in (13 mm)
..........................2,0 kg
..........................2,2 kg
..........................2,6 kg
........................78,5 dB (A)
........................89,5 dB (A)
.......................< 2,5 m/s 2
..........................1,5 m/s 2
.......................< 2,5 m/s 2
..........................1,5 m/s 2
ENGLISH
TECHNICAL DATA Cordless Drill Driver
No-load speed 1st gear ...........................................................
No-load speed 2nd gear ..........................................................
Torque *1 .................................................................................
Battery voltage.........................................................................
Drill opening range ..................................................................
Weight according EPTA-Procedure 01/2003 (Li-Ion 1.5 Ah) ...
Weight according EPTA-Procedure 01/2003 (Li-Ion 3.0 Ah) ...
Weight according EPTA-Procedure 01/2003 (NiCd 2.0 Ah) ....
Noise/vibration information
Measured values determined according to EN 60 745.
Typically, the A-weighted noise levels of the tool are:
Sound pressure level (K = 3 dB(A)) .......................................
Sound power level (K = 3 dB(A)) ............................................
Wear ear protectors!
Total vibration values (vector sum in the three axes)
determined according to EN 60745.
Vibration emission value a
h Drilling into metal ..................................................................
Uncertainty K= ......................................................................
Screwing ...............................................................................
Uncertainty K= ......................................................................
*1 Measured according to AEG norm N 877318
WARNING! Read all safety warnings and all
instructions, including those given in the accompanying
brochure. Failure to follow the warnings and instructions
may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
SAFETY INSTRUCTIONS
Wear ear protectors. Exposure to noise can cause hearing
loss.
Hold power tool by insulated gripping surfaces, when
performing an operation where the cutting accessory
may contact hidden wiring. Cutting accessory contacting
a „live“ wire may make exposed metal parts of the power
tool „live“ and shock the operator.
Sawdust and splinters must not be removed while the
machine is running.
When working in walls ceiling, or floor, take care to avoid
electric cables and gas or waterpipes.
Remove the battery pack before starting any work on the
machine.
Do not dispose of used battery packs in the household
refuse or by burning them. AEG Distributors offer to retrieve
old batteries to protect our environment.
Do not store the battery pack together with metal objects
(short circuit risk).
Use only System GBS chargers for charging System GBS
battery packs. Do not use battery packs from other systems.
Battery acid may leak from damaged batteries under
extreme load or extreme temperatures. In case of contact
with battery acid wash it off immediately with soap and
water. In case of eye contact rinse thoroughly for at least 10
minutes and immediately seek medical attention.
SPECIFIED CONDITIONS OF USE
The battery drill/screwdriver is designed for drilling and
screwdriving for independent use away from mains supply.
Do not use this product in any other way as stated for
normal use.
EC-DECLARATION OF CONFORMITY
We declare under our sole responsibility that this product is
in conformity with the following standards or standardized
documents.
EN 60745-1:2009 + A11:2010
EN 60745-2-1:2010
EN 55014-1:2006 + A1:2009 + A2:2011
EN 55014-2:1997 + A1:2001 + A2:2008
in accordance with the regulations
2011/65/EU (RoHs)
2006/42/EC
2004/108/EC
Winnenden, 2012-09-06
Rainer Kumpf
Director Product Development
Authorized to compile the technical file
WARNING
The vibration emission level given in this information sheet has been measured in accordance with a standardised test given
in EN 60745 and may be used to compare one tool with another. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main applications of the tool. However if the tool is used for different
applications, with different accessories or poorly maintained, the vibration emission may differ. This may significantly increase
the exposure level over the total working period.
An estimation of the level of exposure to vibration should also take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may significantly reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator from the effects of vibration such as: maintain the tool and the
accessories, keep the hands warm, organisation of work patterns.
ENGLISH
BATTERIES
New battery packs reach full loading capacity after 4 - 5
chargings and dischargings. Battery packs which have not
been used for some time should be recharged before use.
Temperatures in excess of 50°C (122°F) reduce the
performance of the battery pack. Avoid extended exposure
to heat or sunshine (risk of overheating).
The contacts of chargers and battery packs must be kept
clean.
For an optimum life-time, after use, the battery packs have
to be fully charged.
BATTERY PACK PROTECTION LI-ION BATTERY
The battery pack has overload protection that protects it
from being overloaded and helps to ensure long life.
Under extreme stress the battery electronics switch off the
machine automatically. To restart, switch the machine off
and then on again. If the machine does not start up again,
the battery pack may have discharged completely. In this
case it must be recharged in the battery charger.
INTENANCE
Use only AEG accessories and spare parts. Should
components need to be replaced which have not been
described, please contact one of our AEG service agents
(see our list of guarantee/service addresses).
If needed, an exploded view of the tool can be ordered.
Please state the Article No. as well as the machine type
printed on the label and order the drawing at your local
service agents or directly at: AEG Electric Tools,
Max-Eyth-Straße 10, D-71364 Winnenden, Germany.
SYMBOLS
Please read the instructions carefully before
starting the machine.
Remove the battery pack before starting any
work on the machine.
Do not dispose of electric tools together with
household waste material! In observance of
European Directive 2002/96/EC on waste
electrical and electronic equipment and its
implementation in accordance with national law,
electric tools that have reached the end of their
life must be collected separately and returned to
an environmentally compatible recycling facility.
BS 18 C
......................0-450 min -1
....................0-1650 min -1
...........................52 Nm
...........................18 V
..........................1/2 in (13 mm)
..........................2.0 kg
..........................2.2 kg
..........................2.6 kg
........................78.5 dB (A)
........................89.5 dB (A)
.......................< 2.5 m/s 2
..........................1.5 m/s 2
.......................< 2.5 m/s 2
..........................1.5 m/s 2
