AEG STEP 1200 BX - Manual (Page 12)

22 23
STEP 1200 BX
.........................600 W
.........................300 W
................500-3000 /min
...........................26 mm
......................... 45°
......................... 110 mm
...........................90 mm
...........................10 mm
...........................20 mm
...........................30 mm
...........................10 mm
..........................2,4 kg
...........................86 dB (A)
...........................97 dB (A)
.............................7 m/s 2
..........................1,5 m/s 2
..........................5,5 m/s 2
..........................1,5 m/s 2
TECHNICAL DATA Jig Saw
Rated input ..............................................................................
Output ......................................................................................
Stroke rate under no–load .......................................................
Lengths of stroke .....................................................................
Bevel cuts up to .......................................................................
Cutting depth max. in:
Soft- wood ............................................................................
Hard-wood ............................................................................
Steel .....................................................................................
Non-ferrous metal .................................................................
Aluminium .............................................................................
Ceramics ..............................................................................
Weight without cable ...............................................................
Noise/vibration information
Measured values determined according to EN 60 745.
Typically, the A-weighted noise levels of the tool are:
Sound power level (K = 3 dB(A)) ............................................
Sound pressure level (K = 3 dB(A)) .......................................
Wear ear protectors!
Total vibration values (vector sum in the three axes)
determined according to EN 60745.
Sawing of wood
Vibration emission value a
h
...................................................
Uncertainty K ........................................................................
Sawing of sheet metal
Vibration emission value a
h
...................................................
Uncertainty K ........................................................................
WARNING! Read all safety warnings and all
instructions, including those given in the accompanying
brochure. Failure to follow the warnings and instructions
Save all warnings and instructions for future reference.
SAFETY INSTRUCTIONS
Wear ear protectors. Exposure to noise can cause hearing
loss.
Hold power tool by insulated gripping surfaces, when
performing an operation where the cutting accessory
may contact hidden wiring or its own cord. Contact with
a „live“ wire will also make exposed metal parts of the power
tool „live“ and shock the operator.
Appliances used at many different locations including open
air should be connected via a residual current device of
30 mA or less.
Always wear goggles when using the machine. It is
recommended to wear gloves, sturdy non slipping shoes
and apron.
Sawdust and splinters must not be removed while the
machine is running.
Always disconnect the plug from the socket before carrying
out any work on the machine.
Only plug-in when machine is switched off.
Keep mains lead clear from working range of the machine.
Always lead the cable away behind you.
Always use the protective shields on the machine.
Do not use cracked or distorted saw blades.
Plunge cuts without pre–drilling a hole are possible with soft
materials (wood, light building materials for walls). Harder
corresponding to the size of the saw blade.
The dust produced when using this tool may be harmful to
health. Do not inhale the dust. Wear a suitable dust
protection mask.
SPECIFIED CONDITIONS OF USE
This jig saw can cut wood, plastic and metal; it can cut
straight lines, bevels, curves, and internal cut–outs.
Do not use this product in any other way as stated for
normal use.
ENGLISH
WARNING
The vibration emission level given in this information sheet has been measured in accordance with a standardised test given
in EN 60745 and may be used to compare one tool with another. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main applications of the tool. However if the tool is used for different
the exposure level over the total working period.
An estimation of the level of exposure to vibration should also take into account the times when the tool is switched off or
Identify additional safety measures to protect the operator from the effects of vibration such as: maintain the tool and the
accessories, keep the hands warm, organisation of work patterns.
ENGLISH
EC-DECLARATION OF CONFORMITY
We declare under our sole responsibility that this product is
in conformity with the following standards or standardized
documents. EN 60745, EN 55014–1, EN 55014–2,
EN 61000–3–2, EN 61000–3–3, in accordance with the
regulations 2006/42/EC, 2004/108/EG
Winnenden, 2010-07-20
Rainer Kumpf
Manager Product Development
MAINS CONNECTION
Connect only to single-phase a.c. current and only to the
system voltage indicated on the rating plate. It is also
possible to connect to sockets without an earthing contact
as the design conforms to safety class II.
Under the effect of extreme electromagnetic interferences
from the outside, temporary variations in the speed of
rotation could arise in particular cases.
MAINTENANCE
The ventilation slots of the machine must be kept clear at all
times.
Use only AEG accessories and spare parts. Should
components need to be exchanged which have not been
described, please contact one of our AEG service
agents (see our list of guarantee/service addresses).
If needed, an exploded view of the tool can be ordered.
Please state the ten-digit No. as well as the machine type
printed on the label and order the drawing at your local
service agents or directly at: Techtronic Industries GmbH,
Max-Eyth-Straße 10, D-71364 Winnenden, Germany.
SYMBOLS
Please read the instructions
carefully before starting the
machine.
Always disconnect the plug from the socket
before carrying out any work on the machine.
Accessory - Not included in standard
equipment, available as an accessory.
Do not dispose of electric tools together with
household waste material! In observance of
European Directive 2002/96/EC on waste
electrical and electronic equipment and its
implementation in accordance with national
law, electric tools that have reached the end of
their life must be collected separately and
returned to an environmentally compatible
recycling facility.
Techtronic Industries GmbH
Max-Eyth-Straße 10
D-71364 Winnenden
