DISTRIBUTION AMPLIFIERS
3
3
•
Any changes or modifications to the unit not
expressly approved by Altinex, Inc. could void
the user’s authority to operate the equipment.
ABOUT YOUR DISTRIBUTION AMPLIFIER 2
The DA1912SX Distribution Amplifier is designed
to allow the connection of one high resolution
RGsB or RGBS source to up two scan rate
compatible monitors or projectors.
Although designed to pass an RGBS signal format,
the DA1912SX can also pass RGsB, Component
Video (Y, R-Y, B-Y), S-Video (Y/C), and Composite
Video by using the appropriate channels. Video
sources must be passed through Red, Green,
and/or Blue channels. The sync channel is not
designed to pass video.
The DA1912SX Distribution Amplifier is a state-of-
the-art product with a video bandwidth of 350 MHz,
enabling it to remain transparent to the video signal
passing through it. Each output is individually
buffered and is not affected by other output
loading.
The DA1912SX accepts one input and offers up to
two outputs. Compensation for cable loss is
automatically made for distances up to 100 feet
when set normally, though the DA1912SX can
drive signals through longer runs depending on
source signal resolution and cable quality.
The DA1912SX is supplied with a 9V 500mA
External Power Adapter.
TECHNICAL SPECIFICATIONS 3
FEATURES/DESCRIPTION DA1912SX
GENERAL
Inputs
1
Input Connector 4 BNC Female
Outputs 2
Output Connectors Two 4 BNC Female
Compatibility High resolution RGBS,
RGsB and RsGsBs,
Component, S-Video
and Composite Video
Table 1. DA1912SX General
MECHANICAL DA1912SX
Width (inches) 4.56in (116mm)
Height (inches) 3.50in (89mm)
Depth (inches) 0.94in (24mm)
Weight (pounds) 0.6lbs (0.27kg)
Ship Weight (pounds) 2.0lbs (0.91kg)
Material 0.1” Al
Finish Gray
Top Panel Lexan
T
°
Operating 10
°
C-35
°
C
T
°
Maximum 50
°
C
Humidity 90
%
non-condensing
MTBF (calculations) 40,000 hrs
Table 2. DA1912SX Mechanical
ELECTRICAL DA1912SX
Input Video Signal
Analog Signal
1.5V p-p max
Impedance 75 Ohms
Input Sync Signal
Horizontal, Vertical, & C-Sync
TTL(+/-)
Sync on Green -0.3V
Impedance 10 k Ohms
Output Video Signal
Analog Signal
1.0V p-p/0.7V p-p
Impedance 75 Ohms
Output Sync Signal
Composite Sync
TTL(+/-)
Sync on Green -0.3V
Impedance 22 Ohms
Frequency Compatibility
Typical Video Bandwidth
380 MHz
Minimum Video Bandwidth 350 MHz
Rise/Fall Time (ns) 1.4
Gain Default Setting 1.05
Cross-talk -40dB @10 MHz
Coupling AC
Power
External Power
9V 500mA external
adapter (included)
Power Consumption 4 watts max.
Table 3. DA1912SX Electrical
