D. controls main unit (refer to figure 1) figure 1 – Audiovox AVD400TA User Manual

Page 6

background image

6

1. Power Button
2. Play/Stop/Memory Button
3. Mode Button
4. Remote Control Sensor
5. Video Input
6. Left Audio Input
7. Right Audio Input
8. Next Button
9. Previous Button
10. Eject Button
11. IR Input
12. Antenna Input
13. Audio R Output Jack
14. Audio L Output Jack
15. Video Output Jack
16. S-Video Output Jack
17. External Remote Eye Input
18. Digital Audio Output
19. DC In 12V Power Supply Connector

D. Controls

Main Unit (Refer to Figure 1)

Figure 1

2

3

AVD400TA

DVDPLAYER

DOLBY

1

C

C

F

DOLBY

1

4

5

6

7

9

8

1 0

1 1

1 2

1 3

1 4

1 5

1 6

1 7

1 8

1 9
