7
Technical Specifications
General
Standards
IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
Protocol CSMA/CD
Data Transfer Rate
Ethernet: 10Mbps (half duplex), 20Mbps (full-duplex)
Fast Ethernet: 100Mbps (half duplex), 200Mbps (full-
duplex)
Topology Star
Network Cables
10BASET: 2-pair UTP Cat. 3,4,5, EIA/TIA- 568 100-ohm
STP
100BASE-TX: 2-pair UTP Cat. 5, EIA/TIA-568 100-ohm
STP
Number of Ports
16 x 10/100Mbps Auto-MDI ports (NS-16T)
24 x 10/100Mbps Auto-MDI ports (NS-24T)
Physical and Environmental
AC inputs 100 to 240 VAC, 50 or 60 Hz internal universal power
supply
Power Consumption 6 watts. (max.)
Temperature Operating: 0
° ~ 40° C, Storage: -10° ~ 70° C
Humidity Operating: 10% ~ 90%, Storage: 5% ~ 90%
Dimensions 440 x 140 x 44 mm (W x H x D)
EMI: FCC Class A, CE Mark Class A, VCCI Class A
Safety CUL, CB
Performance
Transmit Method: Store-and-forward
RAM Buffer: 1.25Mbits per device
Filtering Address Table: 8K entries per device
Packet Filtering/Forwarding Rate: 10Mbps Ethernet: 14,880/pps
100Mbps Fast Ethernet: 148,800/pps
MAC Address Learning: Automatic update
