1-4 American-Lincoln
91 WS
SWEEPING SYSTEM
Type Direct Throw
Main Broom
One place plastic core disposable type. No tool charge. Position can be set to “Restricted Down” or “Free
Float”.
Length 27 inches (68.6 cm)
Diameter 11 inches (27.90 cm)
Bristle Length 3 inches (7.62 cm) long, usable to 1.00 inch
Option Bristle Types Proes, Nylon, High Density Nylon
Side Broom
Rotary disposable type with 1.25 inches (3.17 cm) thick marine grade varnished hardwood disk. Floats over
uneven surfaces and is adjustable for wear. Retracts up to impact. No tool charge.
Diameter 16.00 inches (40.60 cm)
Bristle Type Polypropylene
Hopper
Molded polypropylene construction with handle to dump and levers to remove (no tool).
Volumetric Capacity 3 cu. ft. (85.00 It)
Weight Capacity 220 lbs. (82.06 kg)
Ground Clearance 3 inches (7.62 cm)
Dust Control
One pleated water resistant fibre type panel filter with automatic timed (20 seconds) filter shaker. Patented
shaker system. No tool quick change filter.
Filter Area 40 sq. ft. (3.70 m²)
Impeller 9 inches dia.
OPTIONAL EQUIPMENT
Left Hand Side Broom Low Oil Light
Shaker Switch Foam Filled Tires in Lieu of Solid Tires
MACHINE DIMENSIONS
SPECIFICATIONS
36.00"
91.44 cm
60.00"
152.40 cm
34.00"
86.36 cm
39.00"
99.06 cm
C0606
