Page -19- CLARKE TECHNOLOGY Summit Operator's Manual
CLARKE TECHNOLOGY
Wand and Tool Kit #16414A 8-94
Ref. Part No. Description Qty
1 19200A Carpet Tool Assembly 1
2 39200A Floor Tool 1
3 31207A Bumper 1
4 38500A Carpet Shoe 1
5 19501A Lower Wand Assembly 1
6 636706 Disconnect Pin 1
7 68701A Upper Wand 1
8 674114 Vacuum Hose 1
9 39201A Crevice Tool 1
Ref. Part No. Description Qty
10 19203A 3" Dusting Tool 1
11 35206A Housing 1
12 60713A Bristle 1
13 39202B Upholstery Tool 1
14 19202A Squeegee Tool Assembly 1
15 31207A Bumper 1
16 38503A Rear Squeegee Shoe 1
17 30901A Squeegee Blade 1
18 38502A Front Squeegee Shoe 1
7
8
5
1
2
3
4
6
14
2
15
16
17
18 9
10
11
12
13
