FPM-3220 User’s Manual

Appendix A Display Timing Mode and
OSD

A.1 Supported Input Timing Modes

The nineteen kinds of timings below are already programmed in this
module. The input synchronous signals are automatically recognized.

Table A.1: Supported Input Formats

Note 1:

Even if the preset timing is entered, a little adjust-

ment of the functions such as Horizontal period,

CLK-delay and display position, are required. The

adjusted values are memorized in every preset num-

ber.

Note 2:

This module recognizes the synchronous signals

with near preset timing of the frequency of the HS

and Vsync, even in the case that the signals other

than the preset timing that were entered.

Note 3:

Because adjustments may not fit, such as differing

magnifying ratios or, in the case that you use it

except for the display timing that was preset.

Resolution Vertical Frequencies

60 Hz

70 Hz 72 Hz 75 Hz

640 x 480

Yes

800 x 600

Yes
