Locations, Locating components – Lenovo E50-00 Desktop User Manual
Page 38
33
User Guide
Locations
This section provides illustrations to help locate the various connectors, controls
and components of the computer. To remove the computer cover, refer to
“Removing the computer cover”.
Locating components
The following illustration will help you to locate the various components in your
computer.
Microprocessor fan and heatsink
Memory modules
Optical drive
Hard disk drive
System fan
