7
User Guide
Computer stand
5º
25º
Use the stand to position the display to your preference. It can be rotated 5°
forward and 25° backward.
Basic connector instructions
Note: Your computer may not have all of the connectors described in this
section.
Connector Description
Microphone Use this connector to attach a microphone to your
computer when you want to record sound or if you use
speech-recognition software.
Headphone Use this connector to attach headphones to your
computer when you want to listen to music or other
sounds without disturbing anyone.
USB connector Use this connector to attach a device that requires a USB
connection.
Ethernet connector Use this connector to attach the computer to an Ethernet-
type local area network.
HDMI connector
(optional) Connects to the HDMI connector on your display or TV.
TV-Tuner connector
(optional) Connects to an external antenna to view programs using
the optional TV tuner card.
