43
User Guide
5. Lift up the computer cover from the bottom as shown, and disconnect LVDS
cable from the connector on the motherboard.
Note: Use a flat-head screw driver to separate the computer cover from
the front panel if necessary.
1
2
6. To reattach the computer cover:
a. Reconnect the LVDS cable to the connector on the motherboard.
b. Line up the mounting pins on the computer cover with the mounting holes
on the front panel, then place the computer cover into position.
c. Use the two screws secure the computer cover to the front panel.
