P35 General Assembly Parts List E078rs_2
ITEM 230V 115V 100V SILVER BLACK DESCRIPTION WHERE USED QTY
1 E058AY E058AYB FASCIA ASSEMBLY FRONT OF CHASSIS 1
2 E838CP E838CPB COVER 1
3 HA4V06S HA4V06B M4 x 6mm Screw COVER (SIDE) TO CHASSIS 4
4 8K004 2-WAY JUMPER SOCKET 0.1” M7571-05 ON L882AY (NEAR SWITCH) 2
5 8K006 CONNECTOR 14MM LINK BAR P2148 FITTED TO REAR PANEL 1
7 E060AY REAR PANEL ASSEMBLY CHASSIS REAR 1
8 E804HK HEAT SINK CHASSIS FLOOR 1
9 E804MI MAINS INSULATOR ON CHASSIS FLOOR UNDER POWER
SUPPLY PCB 1
10 E820CH CHASSIS 1
11 E822PM1 FOOT BASE OF CHASSIS 6
12 E861MC 3
RD
CHANNEL BLANKING PLATE REAR PANEL 1
13 E879SL CONFIGURATION LABEL CHASSIS 1
14 E907MC KOOL PAD HEATSINK 1
15 E912MC TRANSISTOR CLAMP HEATSINK 4
16 E920MC HEATSINK CLAMP HEATSINK 1
17 E938MC DAMPING PLATE ON CHASSIS FLOOR 1
18 F022 FUSE HOLDER COVER 2
19 F037 TOROID CLAMP ø90 (METAL) TOP OF TRANSFORMER 1
20 F038 RUBBER WASHER ø90 ON TOP OF TRANSFORMER 1
21 F164 FOAM TAPE FRONT PANEL TO COVER 400m
m
22 F200 9,5 I.D. HOLE BLANKING GROMMET REAR PANEL (FOR LINK BAR) 2
23 E83001 TRANSFORMER GASKET UNDER TRANSFORMER 1
24 HA3V06A M3 x 6mm SCREW POWER & DISPLAY PCB’S 17
25 HA4A12B M4 x 12mm SCREW EARTHING SCREW 1
26 HA5K70A M5 x 70mm BOLT HEATSINK BOLTS 3
27 HA5L20B M5 x 20mm HEX HEAD BOLT BLACK TRANSISTORS TO HEATSINK 4
28 HA6K60A M6 x 60mm BOLT TRANSFORMER 1
29 HE6V06B SFTP TORX SCREW NO.6x6mm BK CHASSIS TO SUB PANEL 4
30 HF4V09B TORX SCREW NO.4x9mm + WASHER COMPONENTS TO REAR PANEL +
COVER TO REAR PANEL + REAR
PANEL TO CHASSIS 16
31 HJ4A00A M4 NUT EARTHING NUT 1
32 HJ4C00D M4 WAISTED NUT EARTH 1
33 HL4SB M4 SHAKE PROOF WASHER EARTH 1
34 HL5EB M5 WASHER BLACK HEATSINK BOLT (AT THE FRONT) 1
35 L882AY WA8511A L894AY A85 POWERAMP PCB CHASSIS FLOOR 1
36 L884TX L884TX L880TX TRANSFORMER CHASSIS FLOOR 1
37 L915CA DISPLAY TO POWERAMP CABLE ASSY L882AY TO L929AY 1
38 L929AY P35 SWITCH PCB SUB PANEL 1
