Off: When the Power turns off or the power
cord has improper connection.
PoE Status
Green: When the PoE powered device (PD) was
connected and the port supplies power
successfully.
Yellow: When the PoE port have the following
failure happens:
• PoE power circuit shortage
• Power over current: over the power
current of PD’s classification
• Out of PoE voltage of 44 ~ 57 VDC
output
Off: No PoE powered device (PD) connected.
PoE MAX
On: When the system was connected to POE PD
and the power resource remain <=7.5W, the
LED lights on, the system will not provide power
to the additional POE PD inserted.
Off: When the system have enough power of
>7.5W.
10/100 Link/ACT
Link/ACT: When the 10M LED lights on, the
respective port is successfully connected to 10M
Ethernet network.
100M: When the 100M LED lights on, the
respective port is successfully connected to
100M Fast Ethernet network. Otherwise, when
the 100M LED is blinking, the port is
transmitting or receiving data on the Fast
Ethernet network.
Off: No Link.
