Specifications
MASTER UNIT
Maximum Load: 300 watts @ 110 VAC
Max. loop length: 1400 ohms
Ringing Voltages: 53-120 RMS
On-Hook Leakage current:
5 micro-amps max. @ 53 volts
Tip & Ring DC Voltage: 53 volts max.
Operating Temperature: 40˚ to 100˚F
Output carrier signal frequency: 100 KHz
(other frequencies available from factory).
REMOTE UNIT
Maximum load: 300 watts @ 110 VAC
Operating Temperature: 40˚ to 100˚F
Output carrier signal frequency: 100 KHz
(other frequencies available from factory).
