Lenovo H500 Desktop User Manual
Page 29
Hardware components
The following illustration shows the components that make up your computer.
1. Microprocessor fan and heat-sink
5. System fan
2. Memory modules
6. Optical drive
3. PCI express adapter card
7. Hard disk drive
4. PCI express adapter connectors
Locating connectors, controls and components
23
