Chapter 8. Locations
This chapter introduces the locations of the computer hardware components.
Locations
This section provides information to help you locate your computer connectors, components, parts on
the system board, and internal drives.
Note: The components in your computer might look slightly different from the illustrations.
Locating connectors, controls, and indicators on the front of your
computer
Figure 1 “Front connector, control, and indicator locations” on page 65 shows the locations of the
connectors, controls, and indicators on the front of your computer.
Figure 1. Front connector, control, and indicator locations
1 Power switch 5 Headphone connector
2 Hard disk drive activity indicator 6 Microphone connector
3 Optical drive eject/close button 7 USB connectors (USB ports 2)
4 Memory card reader (optional)
Locating connectors on the rear of your computer
Figure 2 “Rear connector locations” on page 65 shows the locations of the connectors on the rear of your
computer. Some connectors on the rear of your computer are color-coded to help you determine where to
connect the cables on your computer.
Figure 2. Rear connector locations
1 Voltage-selection switch (available on some
models)
9 PCI Express x16 graphics card slot
2 Power cord connector 10 PCI Express x1 card slots (2)
3 DVI monitor connector 11 Integrated cable lock (Kingston lock) slot
4 VGA monitor connector 12 Padlock loop
5 USB connectors (USB ports 3 to 6) 13 Optional serial port
6 Microphone connector 14 Ethernet connector
7 Audio line-out connector 15 Optional serial port
8 Audio line-in connector
© Copyright Lenovo 2013 65
