Built-in microphone
Hard disk drive indicator
LCD On/Off
Wireless LAN card indicator
Brightness down
Bluetooth indicator
Brightness up
Power button
Left and right view
The following illustrations show the location of connectors on the left and right side
of the computer.
Attention: Be sure not to block any air vents on the computer. Blocked air
vents may cause thermal problems.
2
3
4
1
2
5
Memory card reader
Microphone connector
USB connector
Optical drive
Headphone connector
31043502_B3_HRG_EN_V1.0.indd 5
2010.4.14 4:13:26 PM
