6
Hardware Replacement Guide
Built-in microphone Camera
Power button Built-in IR receiver (only functional on
models equipped with a IR receiver
module)
Hard disk drive indicator Wireless LAN card indicator
LCD ON/OFF indicator (When
turning on the LCD, the indicator
light will be off; when turning off
the LCD, the indicator light will be
solid on.) Menu button
Direction button Direction button
LCD ON/OFF
Left and right views
The following illustrations show the location of connectors and components on the
left and right sides of the computer.
Attention: Be sure not to block any air vents on the computer. Blocked air
vents may cause overheating.
Memory card reader USB ports (2)
Headphone connector Microphone connector
Optical drive
