Step 8. Push the two pin to release the camera 1 , then lift the camera out. 2
Step 9. Disconnect the data cable from the camera. 3
Step 10. Push the pins to release the camera out of housing 4 , then lift the camera out. 5
Step 11. To install the new camera:
a. Line up the new camera with the housing, then insert
b. Connect the data cable to the new camera.
c. Line up then insert the new camera and housing into position, and secure the camera with
the locking pins.
Step 12. Reattach the middle cover, optical drive, computer stand and the rear cover.
Replacing the power switch board
Note: Turn off the computer and wait 3 to 5 minutes to let it cool down before removing the cover.
To replace the power switch board
Chapter 8 . Replacing hardware 37
