Tower, rear view-m5800 – Lenovo M5800 Desktop User Manual
Page 5
4
Safety, Warranty, and Setup Guide
PCI Express x16 graphics card slot
PCI Express x1 card slots (2)
Integrated cable lock (Kensington lock) slot
Padlock loop
Optional serial port
Ethernet connector
Tower, rear view-M5800
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
Voltage-selection switch (available on some models)
Power cord connector
Serial port (Serial port 1)
VGA monitor connector
DisplayPort connector
USB 3.0 connectors (USB ports 5 to 8)
USB 2.0 connectors (USB ports 3 and 4)
Microphone connector
Audio line-in connector
31505253 Lenovo M4350_M5800 SWSG V1.0 (EN)(R).indb 4
2013-7-15 19:16:10
