7.1 Audio configuration instructions
Use the following illustration when connecting a 7.1 surround sound audio system.
S/PDIF out connector Center / Low frequency output
connector
Surround out connector Microphone input Connector
Audio line-out Connector Audio line-in Connector
Note: For more detailed settings, from the Search charm, select Apps →
Control Panel → Hardware and Sound → Lenovo HD Audio Manager.
Follow the instructions to configure advanced settings.
Sound configuration is as follows:
1. Right click the Sound icon in the system property bar and select the Sounds
option to set up sounds in the pop-up dialog box.
2. Select a playback device from the Playback dialog box, then click the
Configure button to configure it.
3. Select 7.1 surround from audio channels in the pop-up Speaker setup dialog
box and proceed with the speaker setup by following the prompts.
