Lenovo IdeaCentre K330B - Manual (Page 41)

Chapter 7. Replacing hardware
39
7. Use the thermal grease syringe to place five drops of grease on the
top of the microprocessor. Each drop of grease should be 0.03ml (3
tick marks on the grease syringe).
8. Install the heat sink and fan assembly on the heat sink retention
bracket.
9. Reconnect the disconnected cables to the system board.
10. Refer to the “Completing the installation”.
Replacing a PCI or AGP adapter
Attention
Do not remove the computer cover or attempt any repair before
reading the “Important safety information” in the Safety and Warranty
Guide that was included with your computer or in the Hardware
Maintenance Manual (HMM) for the computer. To obtain copies of the
Safety and Warranty Guide or HMM, go to the Support Web site at
http://consumersupport.lenovo.com
To replace an adapter:
1. Remove the computer cover. Refer to “Removing the computer cover”.
