Hardware Replacement Guide
Optical drive (Some models are equipped with only one optical drive.)
Power Dial switch
Rear view
The following illustration shows the location of connectors on the rear of the computer.
8
11
12
13
14
9
10
7
1
2
3 4
5
6
Voltage selection switch (selected models only)
Power connector
PS/2 keyboard connector
PS/2 mouse connector
Serial connector (selected models only)
On-board VGA connector (selected models only)
USB connectors (6)
Ethernet connector
Microphone connector
Audio line-out connector
Audio line-in connector
