Page 11
6
Hardware Replacement Guide
PCI express adapter card
PCI express adapter connectors
Power supply
System fan
Optical drive
Hard disk drive
Locating connectors on the front of the computer
The following illustration shows the location of connectors on the front of the
computer.
Power button
Optical Drive (Selected models only)
Memory card reader (Selected models only)
USB connectors (2)
Headphone connector
Microphone connector
