2.3 Self test pattern
The monitor may display a three colors test pattern. This is to indicate that the
monitor is functioning properly, but the computer’s video signal is not reaching
the monitor. In this case, please make sure the video cable is properly connected.
The test pattern will disappear when the monitor is able to receive the video signal.
However, if the test pattern does not display all three colors (blue, green and red),
the monitor is not functioning properly. Please contact your local dealer for
assistance.
2.4 Safety protection
The safety protection function is protecting for the monitor itself. When frequency
of video signal from computer’s was out of range, (please refer to monitor
“specifications”) The monitor will protect by itself and a warning message of OSD
will appear on the screen, warning you to resetting monitor type on your computer.
2.5 Timing guide
This multi-scanning monitor can automatically detect and display several video
modes. If the monitor recognizes one of preset timing signals, it will reset that
mode and any stored display adjustments you have made.
The factory preset modes as indicated in the following table
F
h: Horizontal Frequency (KHz)
Fv : Vertical Frequency (Hz)
3. Technical information
3.1 Products specifications
Picture tube (flat Screen CRT)
Size:
Dot pitch:
Surface / transmission:
17-inch (43.18 cm) diagonal
0.25mm
Tinted screen glass non-glare, black matrix
Maximum viewable area 16.02” (40.69cm) diagonal
Display size (factory setting)
310 mm (H) x 230 mm (V)
12.20 inch (H) x 9.06 inch (V) ( Adjustable)
Synchronization range
Horizontal frequency:
Vertical frequency:
30-86KHz
50-160Hz
Max. Resolution 1600x1200
Recommended resolution 1024x768 /85Hz
Dot Rate 150MHz
Power supply (universal)
Input Voltage:
Consumption:
AC 100-240V 60/50 Hz
110 watts maximum.
Input signal
Video: Analog 0.7Vp -p / 75 Ohms
Sync. : Separate sync. TTL level
Display Analog Input
Unlimited Number of colors
(depends upon video card)
Weight
Net :
Gross :
18.5kg (40.7Lb)
21.0kg (46.2Lb)
Unit dimension (W x H x D) 410 x 412 x 420 (mm)
Operating condition
Temperature:
Humidity:
5
° C~40 ° C (41 ° F to 104 ° F)
20 ~ 80
Storage condition
Temperature:
Humidity:
-20
° ~60 ° C (-4 ° F to 140 ° F)
10 ~ 90
DDC1/DDC2B ( Plug and Play) VESA standard
NOTE: All technical specifications are subject to change without notice.
Mode
Resolution
(dots x lines )
Fh. Fv. Mode
Resolution
(dots x lines)
Fh. Fv.
1 720 Ч 400 31.47 70 7 800 Ч 600 63.90 100
2 640 Ч 480 31.47 60 8 1024 Ч 768 48.36 60
3 640
Ч
480 43.27 85 9 1024
Ч
768 60.02 75
4 800 Ч 600 46.87 75 10 1024 Ч 768 68.67 85
5 800
Ч
600 37.88 60 11 1600
Ч
1200 75.01 60
6 800 Ч 600 53.67 85
