C
ountertop
C
ooking
e
quipment
O
peratOr
’
s
M
anual
4
C
ountertop
C
ooking
e
quipment
5
English
O
peratOr
’
s
M
anual
t
roUbleShooting
9.
Problem it might be caused by Course of action
Pilot Light does not come on when
the temperature control is turned up.
The equipment is not plugged in. Plug equipment in.
Pilot Light malfunction. Replace pilot light.
Power switch malfunction. Replace power switch.
Temperature control malfunction. Replace temperate control.
The pilot light comes on, equipment
does not heat.
Heating Element malfunction. Replace heating element.
S
ervice and
r
epair
There are no user serviceable parts within this appliance. To avoid serious injury or damage, never attempt to repair the equipment or replace a damaged power
cord yourself. Do not send equipment directly to the Vollrath Company. Please contact the qualified professional repair service listed below.
N L1 G
4
2
2
2
2
2
1
3
M
L1 L2
H1 H2
120Volt
Item
40820
Callout Description
1 Control Thermostat
2 Heating Element, 120V ~ 800 Watt
3 Pilot Light, 120V, Amber
4 Power Switch
electrical draWing - h
ot
d
og
r
oller
g
rill
N L1 G
4
2
2
2
2
1 1
3 3
M
L1 L2
H1 H2
2
2
2
L1 L2
H1 H2
120Volt
Item
40821
Callout Description
1 Control Thermostat
2 Heating Element, 120V ~ 800 Watt
3 Pilot Light, 120V, Amber
4 Power Switch
N L1 G
4
2
2
2
2
2
1 1
3 3
M
L1 L2
H1 H2
2
2
2
2
L1 L2
H1 H2
120Volt
Item
40822
Callout Description
1 Control Thermostat
2 Heating Element, 120V ~ 800 Watt
3 Pilot Light, 120V, Amber
4 Power Switch
electrical draWing - h
ot
d
og
r
oller
g
rill
