Callout Part Number Description
1 FFEB400 Fryer Head Assembly, 220V (includes Ref. No. 2, 3, 4, 5, 6, 7, 9, 10, 11, 12, 13, 14, 15, 16, 17, 18)
2 XAA0002 Pilot Light, 220V, Red
3 N/A Control Panel Insert
4 XAA0009 Control Panel Facia
5 N/A Element Box
6 XFFA0004 Thermostat Control Knob
7 XFFA0013 Temperature Safety Switch Cover
8 N/A Temperature Safety Switch Label
9 XFFA0008 Thermostat
10 XFFA8008 Temperature Safety Switch Sensor (Over Temperature Safety Thermostat)
11 XFFA5010 Micro Switch
12 N/A Safe Operation Switch
13 N/A Back Plate
14 XCOA1013 Power Cord Restraint
15 XAA0006 Power Cord, 220V, NEMA 6-15P Plug
16 N/A Element Cover
17 XFFA8001 Heating Element, 220V ~ 3000 Watt
18 XFFA8030 Relay
19 FFB1250 Basket, Small
20 FFB2250 Basket, Large
21 N/A Food Screen
22 N/A Fryer Body, Single
23 N/A Fryer Body, Double
24 XFFA8011 Foot, Rubber
25 XFFA8027 Night Cover
26 XFFA8002 Drain Valve Assembly (includes Ref. No. 29)
27 N/A Trim Ring
28 XFFA8100 White Plastic Plug to Activate Safety Switch
29 XFFA8012 Drain Valve Handle
spare parts list - c
oUntertop
f
ryer
, m
odels
~ 40709
and
, 40710
