spare parts list - g
rinder
~ 40743
Callout Part number Description
1 XMIN1224 FEEDER PAN
2 XMIN2202 MEAT PUSHER
3 XMIN1226 BRASS BUSH FOR CHAMBER
4 XMIN1204 GRINDING CHAMBER HEAD
5 XMIN1203 COUPLING COVER NUT
6 40747 PLATE 1/8" (was XMIN1207)
6 40748 PLATE 1/4" (was XMIN1208)
6 40749 PLATE 1/2" (was XMIN1209)
7 40746 GRINDER KNIFE (was XMIN1206)
8 XMIN1232 WORM SHAFT FRONT
9 N/A WORM
10 XMIN1231 WORM SHAFT REAR
8/9/10 XMIN1205 WORM (SPIRAL PROPELLER ASSEMBLY)
11A XMIN1210 GEARBOX COMPLETE (#11A,12,13,14,15,17,31,33,35,36,38,39,42,43)
15 XMIN1218 BRASS WORM GEAR
16 XMIN1222 WORM DRIVE GEAR SPIRAL
18A XMIN1221 MOTOR
22 XMIN1219 PLASTIC BASE PLATE
23 XMIN1212 CAPACITOR, 200mfd 125V AC
24 XAA0012 CABLE RESTRAINT
27 XMIN1213 THUMBSCREW
28 XMIX2004 GOVERNOR PLATE
29 XMIN1215 GOVERNOR
30 XMIN1216 ON/OFF SWITCH
31 XMIX3086 BEARING, 6205Z
32 XMIN1225 RESET SWITCH
33 XSLS6203 BEARING, 6203
35 XMIN2230 OIL SEAL, 30 X 45 X 8
36 N/A CIRCLIP A15
37 XMIN1217 MEAT FUNNEL
39 XMIN1230 KEY, (6X6X15)
42 N/A HEX BOLT
43 XMIX2290 FREEZE PLUG
45 XMIN1220 FEET
48 XAA0005 POWERCORD, 120V, NEMA5-15P PLUG
49 XMIN1229 PLASTIC HANDLE
50 XMIN1223 GREASE TRAPPER BOLT
52 XMIN1228 HANDLE HEXBOLT
53 XMIN1211 SPACER
