Pfannenberg PRH 030-M User Manual
Pfannenberg Radiators

Heaters, Thermostats and Hygrostats
234
235
Heaters, Thermos
-
tats and Hygrostats
Further technical information can be found on the Internet:
www.pfannenberg.com
www.pfannenberg.com
Data
PRH 010-M
PRH 020-M
PRH 030-M
Unit
Article number
17000105317
17000205317
17000305317
Heating performance (Ta = +20 °C)
10
20
30
W
Max. surface temperature
95
115
140
°C
Power consumption
10
20
30
W
Starting current
1.0
1.1
1.2
A
Weight
85
120
120
g
Sytem of protection for intended
purpose of use
IP 54
Rated voltage
230 V AC 50 / 60 Hz
Functional range
110 - 250 V AC 50 / 60 Hz
Duty cycle
100%
Operating temperature range
- 40 … + 70 / - 40 … + 158
°C / °F
Storage temperature range
- 40 … + 70 / - 40 … + 158
Installation orientation
as desired, preferably vertical
Device construction
aluminium profile, black anodised
Type of mounting
snap fastening for 35 mm profile bars according to EN 60715
Protection class
II
Type of connection
connecting cable (300 mm)
Mini-Radiant Heaters
PRH 010-M – PRH 030-M
The PRH Mini series of radiant heaters consists of three
versions with heating performance ratings of 10, 20 and
30 Watts. The new mini-heaters by Pfannenberg are
particularly suitable for use in small housings or for the
heating of isolated spots in sensitive areas.
Dimensions
mm
PRH
X
29.5
Y
45
Z
50
L
300
Accessories
Piece
Article number
Information on page
Thermostat
1
17111000000
244/246
Hygrostat
1
17207000000
248
Internal enclosure fan
1
18110000000
85
Approvals see page 229
Y
X
Z
L
