ASSEMBLY

Lay the cart body on its side. Take one of the base feet (legs) and attach it to the

cart body so that the longer leg is attached at the same end (of the cart) as the

power and heat controls. To attach each leg it will take four of the 1" screws.

Set one linking bar at each end. Fit the linking bar down over the extrusion

on the base foot securely, and use one 1" screw at each end to attach.

While the cart is still on its side, attach the second base foot. Make sure the base foot slides

under the top lip of the cart and into position. Then ease both extrusions (on the base foot)

into the linking bar at both ends matching up the screw holes. To secure these it will take

four 1” screws. TIP: At this point, turn the entire cart body on end. This will allow you to

view and tighten any loose screws and catch any screw (holes) you might have missed.

Lay the cart on its side once again to attach the wheels. Put one wheel rod

into the hole from the inside out. Place one spring washer between frame

and wheel and screw on ball cap nut using wrench to tighten.

While you have the cart on its side, attach the cold box to the cart at the roller end

of the cart. This will allow the floor to support the weight of the cold box while

you locate the screw holes and attach the box using four ¼" flat end screws.

Now turn the cart over so that you can attach the second wheel.

Stand the cart up. Attach the pulling bar assembly (side shelf) above the power and

heat control selection controls using the four 1" screws. TIP: If you secure one upper

left corner screw then fasten one lower right corner screw, the tray is now attached

sufficiently to use both hands to fasten the remaining two screws and level the tray.

Set the double upper shelf with sneeze/wind guard on the top of the cart. Line

up the holes on each end and use four ¼" pointed end screws to secure.

Set the umbrella in the receptor hole located between the rollers and the small warming

compartments. Should you choose to leave the umbrella off at this point of the assembly

process, insert the white silicone cap provided into the receptor hole, and your Large Hot

Dog Cart and Umbrella is now ready to use.
