Your video input card is suitable for use with home-quality
video equipment. This chapter lists the specific technical
characteristics of the video card.
Input standards
Video input standards are the same as the following
television input standards:
m NTSC: 525 lines per frame, 60 fields per second
m PAL: 625 lines per frame, 50 fields per second
m SECAM: 625 lines per frame, 50 fields per second
External connections
The external connections on your video input card include
the following:
m an S-video Video In port with a DIN-7 (Deutsche Industrie
Normung) connector
Maximum current from S-video: 0.5 Amperes
m an RCA Video In port (with a yellow sleeve)
m a left RCA Audio In port (with a white sleeve)
m a right RCA Audio In port (with a red sleeve)
77
C H A P T E R
5
Technical Information
