Chapter 1
1-5 Getting Started
LAN 1x Killer E2205 Gigabit LAN controller*
* The Killer Network Manager is only available for Windows 7 and Windows 8/ 8.1 currently.
The supported drivers for other operating systems would be available on the website if
provided by vendor.
■
Back Panel
Connectors
1x PS/2 keyboard/ mouse combo port
2x USB 2.0 ports
1x Clear CMOS button
8x USB 3.0 ports
1x Optical S/PDIF OUT connector
2x HDMI ports
1x DisplayPort
1x LAN (RJ45) port
6x OFC audio jacks
■
■
■
■
■
■
■
■
■
Internal
Connectors
1x 24-pin ATX main power connector
1x 8-pin ATX 12V power connector
8x SATA 6Gb/s connectors
1x M.2 port
2x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
1x USB 3.0 connector (supports additional 2 USB 3.0 ports)
2x 4-pin CPU fan connectors
3x 4-pin system fan connectors
1x TPM module connector
1x Serial port connector
1x Front panel audio connector
1x Direct audio power connector
2x System panel connectors
1x Chassis Intrusion connector
1x Clear CMOS jumper
9x V-Check connectors
1x Power button
1x Reset button
1x OC Genie button
1x Multi-BIOS switch
1x Audio power switch
1x Slow mode booting switch
1x 2-Digit Debug Code LED
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
I/O
Controller
NUVOTON NCT6792 Controller Chip ■
Hardware
Monitor
CPU/System temperature detection
CPU/System fan speed detection
CPU/System fan speed control
■
■
■
BIOS
Features
2x 64 Mb flash
UEFI AMI BIOS
ACPI 5.0, PnP 1.0a, SM BIOS 2.7, DMI 2.0
Multi-language
■
■
■
■
