Gettng Started

MS-7660

Chapter 1

1-3

Gettng Started

MS-7660

Chapter 1

Connectors

Back panel

1 PS/2 keyboard port

1 PS/2 mouse port

1 Clear CMOS button

1 Coaxal S/PDIF-Out port

1 Optcal S/PDIF-Out port

6 USB 2.0 ports

1 USB 3.0 port

1 IEEE 1394 port

1 LAN port

6 flexble audo ports

On-Board

3 USB 2.0 connectors

1 USB 3.0 connector

1 IEEE 1394 connector

1 Chasss Intruson connector

1 S/PDIF-Out connector

1 Front Panel Audo connector

1 Seral Port connector

1 TPM Module connector

1 Power button

1 Reset button

1 Green Power button

1 OC Gene button

Slots

2 PCIE x16 slots

Supports Mult-GPU computng technology

Supports ATI CrossFreX

TM

technology

3 PCIE x1 slots

1 PCI slot, supports 3.3V/ 5V PCI bus Interface

Form Factor

ATX (24.5cm X 30.5 cm)

Mountng

9 mountng holes

■

-

-

-

-

-

-

-

-

-

-

■

-

-

-

-

-

-

-

-

-

-

-

-

■

-

-

■

■

■

■
