Hardware Setup MS-7666
Chapter 2
2-13
Hardware Setup MS-7666
Chapter 2
ESATA Port
The ESATA (External SATA) port is for attaching the ESATA hard drive.
ESATA/ USB 2.0 Combo Port
The ESATA/USB 2.0 combo port is for attaching the ESATA external hard drive or USB
device.
USB 3.0 Port
USB 3.0 port is backward-compatible with USB 2.0 devices. Supports data transfer rate
up to 5 Gbit/s (SuperSpeed).
Important
If you want to use a USB 3.0 device, you must use the USB 3.0 cable to connect to
the USB 3.0 port.
LAN
The standard RJ-45 LAN jack is for connection to
the Local Area Network (LAN). You can connect a
network cable to it.
LED Color LED State Condition
Left Yellow Off LAN link is not established.
On(Steady state) LAN link is established.
On(brighter & pulsing) The computer is communicating with another computer on the LAN.
Right Green Off 10 Mbit/sec data rate is selected.
On 100 Mbit/sec data rate is selected.
Orange On 1000 Mbit/sec data rate is selected.
▶
▶
▶
▶
Yellow Green/ Orange
