1-5 Getting Started
Internal
Connectors
1x 24-pin ATX main power connector
1x 4-pin ATX 12V power connector
4x SATA 6Gb/s connectors
2x SATA 3Gb/s connectors
2x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
1x USB 3.0 connector (supports additional 2 USB 3.0 ports)
1x 4-pin CPU fan connector
1x 4-pin system fan connector
1x 3-pin system fan connector
1x Clear CMOS jumper
1x Front panel audio connector
2x System panel connectors
1x TPM module connector
1x Serial port connector
1x Parallel port connector
1x Chassis Intrusion connector
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
I/O
Controller
NUVOTON NCT6779 Controller Chip ■
Hardware
Monitor
CPU/System temperature detection
CPU/System fan speed detection
CPU/System fan speed control
■
■
■
BIOS
Features
1x 64 Mb flash
UEFI AMI BIOS
ACPI 5.0, PnP 1.0a, SM BIOS 2.7, DMI 2.0
■
■
■
Special
Features
Military Class 4
OC Genie 4
CLICK BIOS 4
SBA(Small Business Advantage)
All Solid CAPs
PCI Express Gen 3
USB 3.0
SATA 6Gb/s
HDMI
Command Center
Live Update
M-Flash
■
■
■
■
■
■
■
■
■
■
■
■
Software Drivers
MSI
Command Center
Super Charger
Super RAID
Live Update 5
Fast Boot
7-ZIP
Intel Turbo Boost Monitor
Intel Extreme Tuning Utility
Intel Small Business Advantage
Norton Internet Security Solution
Trend Micro SafeSync
■
■
-
-
-
-
-
■
■
■
■
■
■
Form
Factor
Micro-ATX Form Factor
9.0 in. x 9.6 in. (22.8 cm x 24.4 cm)
■
■
