Chapter 2 – MSI X79A-GD45 (8D) User Manual
Page 63
BIOS Setup
MS-7760
Chapter 2
2-13
BIOS Setup
MS-7760
Chapter 2
tWRDRDD
Wrte-Read Dfferent Ranks same or Dfferent DIMM.
tRWSR
Read-Wrte Same Rank.
Vdroop Control
Load lne droop controls the stream of current to the CPU.
[Auto]
Automatcally sets values for maxmum stablty.
[Low VDroop]
Provdes less fluctuaton (better for overclockng).
CPU Core OCP Expander
Ths tem s used to expand the lmtaton of CPU Over Current Protecton. The hgh-
er expandng value ndcates less CPU protecton. So please adjust the CPU voltage
carefully f needed, or t may damage the CPU.
CPU Core Engne Speed
Ths tem allows you to ncrease the PWM workng speed to stablze CPU Core volt-
age and mnmze rpple range. Increasng the PWM workng speed wll cause hgher
temperture of MOSFET. So please make sure a coolng soluton s well-prepared for
MOSFET before you ncrease the value.
CPU Core Voltage/ System Agent Voltage (SA)/ CPU I/O Voltage/ CPU PLL Voltage/
CPU Overrde Voltage/ DDR CH_A/B Voltage/ DDR CH_C/D Voltage/ DDR CH_A CA
Vref Voltage/ DDR CH_B CA Vref Voltage/ DDR CH_C CA Vref Voltage/ DDR CH_D
CA Vref Voltage/ DDR CH_A DQ Vref Voltage/ DDR CH_B DQ Vref Voltage/ DDR CH_
C DQ Vref Voltage/ DDR CH_D DQ Vref Voltage/ PCH 1.1 Voltage/ PCH 1.5 Voltage.
These tems are used to adjust the voltages.
Current CPU Core Voltage/ Current SA Voltage/ Current CPU I/O Voltage/ Current
CPU PLL Voltage/ Current DDR CH_A/B Voltage/ Current DDR CH_C/D Voltage
These tems show current voltages. Read-only.
Overclockng Profiles
Press
Overclockng Profile 1/ 2/ 3/ 4/ 5/ 6
Press
Set Name for Overclockng Profile 1/ 2/ 3/ 4/ 5/ 6
Gve a name by typng n ths tem.
Save Overclockng Profile 1/ 2/ 3/ 4/ 5/ 6
Save the current overclockng settngs to ROM for selected profile.
Load/ Clear Overclockng Profile 1/ 2/ 3/ 4/ 5/ 6
Load/ Clear the stored profile settngs from ROM.
Overclockng Profile Save
Save the current overclockng settngs to USB flash dsk.
Overclockng Profile Load
Load the stored settngs from USB flash dsk.
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
