1-3

MS-7676

Chapter 1

Connectors

Back panel

1 PS/2 keyboard/ mouse combo port

4 USB 2.0 ports

1 IEEE 1394 port (Z68MA-ED55 (B3))

1 Optcal S/PDIF port

1 HDMI port**

1 VGA port**

1 DVI-D port**

1 LAN port

2 USB 3.0 ports

6 flexble audo ports

**(The VGA, DVI-D & HDMI ports only work wth Integrated Graphcs Processor)

On-Board

4 USB 2.0 connectors

1 IEEE 1394 connector (Z68MA-ED55 (B3))

1 Chasss Intruson connector

1 S/PDIF-Out connector

1 Front Panel Audo connector

1 TPM Module connector

1 Seral connector (Z68MA-ED55 (B3))

1 set voltage check pont (Z68MA-ED55 (B3))

1 OC Gene button

1 Power button (Z68MA-ED55 (B3))

1 Reset button (Z68MA-ED55 (B3))

Slots

2 PCIE x16 slots

the first PCIE x16 slot (PCI_E1) supports up to PCIE x16 speed

the second PCIE x16 slot (PCI_E4) supports up to PCIE x4 speed

2 PCIE x1 slots

If both PCIe x1 slots (PCI_E2, PCI_E3) are occuped, only the PCI_E2 slot wll be

functonal.

Form Factor

Mcro-ATX (24.5 cm X 24.5 cm)

Mountng

8 mountng holes

■
