Hardware Setup ▍ MS-7551
2-13
Hardware Setup ▍ MS-7551
Fan Power Connectors: CPUFAN, SYSFAN1, SYSFAN2
The fan power connectors support system coolng fan wth +12V. When connectng the
wre to the connectors, always note that the red wre s the postve and should be con-
nected to the +12V; the black wre s Ground and should be connected to GND. If the
manboard has a System Hardware Montor chpset on-board, you must use a specally
desgned fan wth speed sensor to take advantage of the CPU fan control.
1.Gro
und
2.+1
2V
3.Se
nsor
1.Gro
und
2.+1
2V
3.Se
nsor
4.Co
ntrol
1.Gro
und
2.+1
2V
3.No
Use
CPUFAN SYSFAN1 SYSFAN2
Important
Please refer to the recommended CPU fans at processor’s offical webste or consult
the vendors for proper CPU coolng fan.
CPUFAN supports fan control. You can nstall Dual Core Center utlty that wll auto-
matcally control the CPU fan speed accordng to the actual CPU temperature.
Fan cooler set wth 3 or 4 pns power connector are both avalable for CPUFAN
Chasss Intruson Connector: JCI1
Ths connector connects to the chasss ntruson swtch cable. If the chasss s opened,
the chasss ntruson mechansm wll be actvated. The system wll record ths status
and show a warnng message on the screen. To clear the warnng, you must enter the
BIOS utlty and clear the record.
1.CIN
TRU
2.Gro
und
CD-In Connector: JCD1
Ths connector s provded for external audo nput.
4.R
3.Gro
und
2.Gro
und
1.L
•
•
•
