Chapter 1
Connectors & Buttons
Back panel
1x PS/2 keyboard/ mouse port
1x Clear CMOS button
1x Coaxal S/PDIF-out port
1x Optcal S/PDIF-out port
4x USB 2.0 ports
2x USB 3.0 ports
1x LAN port
6x audo ports
1x HDMI ® port**, supportng a maxmum resoluton of 1920x1200
1x DVI-D port**, supportng a maxmum resoluton of 1920x1200
1x VGA port**
** Ths platform supports dual-dsplay functon by any two output ports (HDMI+DVI,
DVI+VGA or VGA+HDMI).
On-Board
3x USB 2.0 connectors
1x USB 3.0 connector
1x TPM Module connector
1x Front Panel Audo connector
1x Chasss Intruson connector
1x Voce Gene connector (optonal)
1x MultConnect Panel connector (optonal)
1x V-Check Ponts Set (optonal)
Slots
2x PCIe 3.0 x16 slots
1x PCIe 2.0 x16 slot
PCI_E7 supports up to PCIe 2.0 x4 speed (when PCI_E3 or PCI_E6 s empty) or
PCIe 2.0 x2 speed (when PCI_E3 or PCI_E6 s nstalled).
4x PCIe 2.0 x1 slots
Form Factor
ATX (30.5 cm X 24.5 cm)
Mountng Screw Holes
9x mountng holes
■
-
-
-
-
-
-
-
-
-
-
-
-
■
-
-
-
-
-
-
-
-
■
■
-
■
■
■
